Air System How to Install the Range Actuator Valve Special Instructions Apply Eaton lubricant #71214 or equivalent to the O-ring so a film covers the entire surface of each O-ring.
Special Tools •
Typical Service Tools
Procedure -
31
1.
Install the actuating pin in the range actuator valve bore.
2.
If previously removed, replace the air fittings
3.
Install the range actuating valve.
4.
Position the range actuating valve bracket and lockwasher over the capscrew openings. The newest design of the range actuator does not have the bracket.
5.
Apply Eaton sealant #71205 or equivalent to the retaining capscrews.
