Air System How to Remove the Range Actuator Valve Special Instructions The air lines must be depressurized.
Special Tools •
Typical Service Tools
Procedure From the mounting screws, bend the lockwasher retaining tabs down.
2.
From the range actuator valve bracket, remove the two (2) mounting screws. The newest design of the range actuator does not have the bracket.
3.
Remove the range actuator valve lockwasher, bracket, and range actuator valve.
4.
Inspect the air fittings, remove if damaged.
5.
From the range actuator valve bore, remove the actuating pin.
6.
Inspect the actuating pin for damage, replace if necessary.
External Parts
1.
30
