Integral Oil Pump How to Assemble the Integral Oil Pump Special Instructions When installing the drive shaft keys, the round key goes in the round keyway and the square key in the square keyway.
Special Tools •
Typical Service Tools
•
A vise with brass jaws or wood blocks
Procedure -
171
1.
Install the relief valve in the integral oil pump housing.
2.
Install the relief valve spring in oil pump housing.
3.
Secure the oil pump housing in a vice.
4.
Depress the relief valve spring and drive the relief valve retention roll pin into the roll pin bore.
5.
If removed, replace the drive shaft snap ring on the pump drive shaft.
6.
Insert the drive shaft through the pump housing bore.
7.
Install the two (2) keys on the drive shaft.
8.
Align the inner element keyways with the drive shaft keys and install the integral oil pump inner element.
