How to Assemble the Auxiliary Section How to Assemble the Splitter Cylinder Assembly Special Instructions Apply Eaton lubricant #71214 or equivalent to all shift cylinder assembly and insert valve O-rings so a film covers the entire surface of each O-ring. Apply Eaton rust preventative #71213 or equivalent to all shift cylinder walls and yoke bars, cover the entire yoke bar surface that comes in contact with the shift cylinder O-ring. Apply Eaton lockwire #1619 or equivalent to the shift yoke capscrews. The lockwire should anchor each capscrew head securely to the yoke or to the second capscrew which fastens to the yoke bar. The lockwire should be twisted together, trimmed, and bend out of the way of other parts.
Special Tools •
Typical Service Tools
•
A vise with brass jaws or wood blocks
Procedure If previously removed, in the cylinder housing bore, install the small O-ring.
2.
If previously removed, on the piston O.D., install the piston O-ring.
Auxiliary Section
1.
158
