How to Assemble the Auxiliary Section How to Assemble the Range Cylinder Assembly Special Instructions Apply Eaton lubricant #71214 or equivalent to all shift cylinder assembly and insert valve O-rings so a film covers the entire surface of each O-ring. Apply Eaton rust preventative #71213 or equivalent to all shift cylinder walls and yoke bars, cover the entire yoke bar surface that comes in contact with the shift cylinder O-ring. Apply Eaton lockwire #1619 or equivalent to the shift yoke capscrews. The lockwire should anchor each capscrew head securely to the yoke or to the second capscrew which fastens to the yoke bar. The lockwire should be twisted together, trimmed, and bent out of the way of other parts.
Special Tools •
Typical Service Tools
Procedure -
153
1.
If previously removed, install the interlock pin in the cylinder housing. ("A" Series Only).
2.
If previously removed, install the roll pin. ("A" Series Only).
