Countershaft Assembly (A Series Only) How to Install the Countershaft Assemblies (w/Ball Bearings) A Series Special Instructions For ease of assembly, mount the auxiliary section in a vise. When Installing the countershaft assemblies into the countershaft bearings, keep the countershaft assemblies straight. Do not cock the countershafts. If, when the countershaft bearing cover is removed and you can not see the snap ring groove, install the cover and drive the countershaft further until you can see the groove.
Special Tools •
Typical Service Tools
•
Vise with brass jaws or wood blocks
•
Bearing driver and a maul
•
Toolmaker’s dye
•
Large snap ring pliers
Procedure Place the countershaft assembly vertical on a clean, flat surface. If previously removed, using the proper driver and maul install the countershaft bearing race.
2.
In the countershaft rear bearing bore, using the proper driver and maul, install the countershaft bearing.
Auxiliary Section
1.
150
