How to Assemble the Auxiliary Section How to Assemble the Output Shaft Assembly Special Instructions For "A" Series, go to “A” Series Section. Make sure the magnetic plugs are installed in the auxiliary housing. Output shaft stack up should be done on a clean, flat surface. When heating the bearings, do not heat bearings above 275°F (136°C). When installing the rear bearing race, the proper depth is when the race shoulder is seated on bearing bore top. Because the collar becomes distorted when compressed, do not use an old nylon collar in the rear bearing cover.
Special Tools •
Typical Service Tools
•
Toolmaker’s dye
•
Heat lamp or hot plate and oil
•
Oil seal installation tool
Procedure 1.
Use toolmaker’s dye and mark the LO range gear for timing purposes. Mark any two (2) adjacent teeth on the LO range gear. Repeat the procedure for the two (2) adjacent teeth directly opposite the first set marked.
Auxiliary Section
2.
With splined washer facing up, place the washer on the output shaft shoulder.
140
