How to Disassemble the Auxiliary Section How to Disassemble the Splitter Cylinder Assembly Special Instructions When removing the splitter cylinder cover insert valve, note the direction the insert valve was positioned (nipple in or out).
Special Tools •
Typical Service Tools
•
A vise with brass jaws or wood blocks
Procedure -
137
1.
From the splitter cylinder cover, remove the capscrews, cover, and gasket.
2.
Clean the gasket mounting surface of gasket material.
3.
From the cylinder housing, remove the yoke bar.
4.
From the auxiliary housing, remove the splitter cylinder housing.
