Countershaft Assembly (A Series Only) How to Remove the Countershaft Assemblies (w/Ball Bearings) A Series Special Instructions For ease of disassembly, mount the auxiliary section upright in a vise. Both countershafts are removed the same. When driving that countershaft to the rear, be careful not to damage the bearing inner race. As the rear bearing is removed, the countershaft will fall.
Special Tools •
Typical Service Tools
•
Vise with brass jaws or wood blocks
•
Bearing puller
•
Soft bar and a maul
Procedure From the countershaft rear bearing cover, remove the capscrews, cover, and gasket.
2.
Clean the gasket mounting surface of gasket material.
3.
From the countershaft rear, remove the snap ring.
Auxiliary Section
1.
128
