How to Disassemble the Auxiliary Section How to Remove the Countershaft Assemblies (w/Tapered Bearings) Special Instructions For "A" Series, go to “A” Series Section. For ease of disassembly, mount the auxiliary section upright in a vise. Both countershafts are removed the same. Make sure the countershaft retaining straps are installed. As the countershaft strap is removed, support the countershaft; it can fall.
Special Tools •
Typical Service Tools
•
Vise with brass jaws or wood blocks
•
Bearing puller
•
Soft bar and a maul
Procedure On the output shaft, temporarily install a output yoke.
2.
To keep the output shaft from turning, insert a breaker bar.
3.
From the output shaft, loosen the 15/16" capscrew and retainer. Do not remove the capscrew. Remove the bar and output yoke.
Auxiliary Section
1.
126
