Specifications Torque Chart The chart below lists the torque values for all the fasteners used on this model transmission. The torque values are also given in the procedures any time a fastener must be tightened. Table Description
Torque Value lb·ft (Nm)
Thread Size
Shift Knob Jam Nut
35–45 (48–61)
1/2” X 13
Shift Lever Housing Capscrews
47–52 (63–70)
M10 X 1.5 X30MM
Remote Shift Control Mounting Cap- 47–52 (63–70) screws
M10 X 1.5 X30MM
Clutch Release Yoke Capscrews
35–45 (48–61)
3/8” X 24
Clutch Release Adjusting Arm Capscrews
35–45 (48–61)
3/8” X 24
Clutch Housing Flange Capscrews
See engine manufacturer recommendations for type, size, and assembly torque.
Rear Support Studs
60 Minimum (81)
M16 X 2.0
Rear Support Stud Nuts
170-190 (230257)
M16 X 1.5
Speed Sensor Retaining Capscrews
20-23 (27-31)
M8 X 1.25
PTO Cover Capscrews/Studs
47-52 (63-70)
M10 X 1.5 X20MM
External Attachment Stud Nuts
20-23 (27-31)
M8 X 1.25
Thermocouple Plug
47-52 (63-70)
1/2" NPT
Use thread sealant
Oil Fill Plug
35-50 (47-67)
1 1/16" X 12
O-ring plug
Oil Drain Plug
35-50 (47-67)
1 1/16" X 12
O-ring plug
Air System Diagnostic Port Plugs
84-120 lb. in.
1/16"-27
Use thread sealant
Oil Level Site Glass
60-70 (81-95)
1 5/8" X 12
O-ring fitting
Air Filter/Regulator Capscrews
9-10 (12-14)
M6 X 1.0 X 55MM
Neutral Switch
15-20 (20-27)
M16 X 1.5
O-ring seal
Reverse Switch
15-20 (20-27)
M16 X 1.5
O-ring seal
Splitter Detent Plug
15-20 (20-27)
M16 X 1.5
O-ring seal
Output Shaft Nut
450-500 (610677)
M48 X 2.0
Oil at yoke installation
Cooler Inlet & Outlet Fittings
40-50 (54-67)
7/8" UNF
O-ring fitting
Main Case Breather
15-20 (20-27)
1/4" X 18
Use thread sealant
9
Drive until bottomed (When using plugs apply 71206 sealant)
