Removing the LCD Bezel 1. See “Removing the LCD Bracket Extensions” on page 79. 2. Remove the four screw caps and screws from the LCD Bezel. NOTE: The two center screw caps at the top of the bezel are for protection only.
Step LCD Bezel
Size M2*6
Quantity
Screw Type
4
3. Starting from the inside top edge, pry the bezel away from the panel. Continue moving down the sides until the bezel is removed. If necessary, use a plastic pry to release the corners of the bezel.
