Removing the Power Board 1. See “Removing the Upper Cover” on page 54. 2. Remove the single securing screw from the Power Board.
Step Power Board
Size M2*3
Quantity
Screw Type
1
3. Disconnect the FFC adhesive from the Upper Cover as shown.
4. Lift up the right side of the Power Board as shown, ensuring that the board is free of the securing pin.
