Power The Power screen allows the user to configure CPU and power management options.
Information
Main
InsydeH20 Setup Utility Security Boot Power Exit
Advanced
Rev. 3.5 Item Specific Help
XAdvanced CPU Control XPlatform Power Management ACPI S3: Wake on PME Wake on Modem Ring Auto wake on S5 Quickly S4 Resume
F1 Help ESC Exit
These items control various CPU parameters.
[Enabled] [Disabled] [Disabled] [Disabled] [Disabled]
Select Item Select Menu
F 5 / F 6 C h a n g e Va l u e s SubMenu Enter Select
F9 F 10
Setup Default Save and Exit
The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter
26
Description
Submenu Items
Advanced CPU Control
Enter the Advanced CPU Control menu.
• • • • • • • • • • • • •
IST Configuration Thermal Mode CMP Support Use NX capability C-State support Enhanced C-States Enable Pop Up Support Pop Down Support Hard C4E Bi-directional PROCHOT# ACPI 3.0 T-States DTS Enable Thermal Trip Points Setting (Throttle On Temp.)
Platform Power Management
Enter the Platform Power Management menu.
• •
PCI Clock Run _CST - C4 Latency Value
ACPI S3
Enable or Disable ACPI S1/S3 Sleep State.
N/A
Wake on PME
Disable or Enable wake up when the system power is off and a PCI Power Management Enable wake up event occurs.
N/A
Wake on Modem Ring
Disable or Enable wake up when the system power is off and a modem attached to the serial port is ringing.
N/A
Chapter 2
