Main The Main screen allows the user to set the system time and date as well as enable and disable boot option and recovery.
Information
Main
InsydeH20 Setup Utility Security Boot Power Exit
Advanced
Rev. 3.5 Item Specific Help
System Time: System Date:
[19:10:59] [01/09/2009]
Total Memory: Video Memory:
1024 MB [8MB]
Quick Boot Network Boot F12 Boot Menu D2D Recovery SATA Mode
[Enabled] [Enabled] [Disabled] [Enabled] [AHCI]
F1 Help ESC Exit
This is the help for the hour field. Valid range is from 0 to 23. INCREASE/REDUCE: F 5 / F 6
F 5 / F 6 C h a n g e Va l u e s SubMenu Enter Select
Select Item Select Menu
F9 F 10
Setup Default Save and Exit
NOTE: The screen above is for your reference only. Actual values may differ. The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter
Description
Format/Option
System Time
Sets the system time. The hours are displayed with 24hour format.
Format: HH:MM:SS (hour:minute:second)
System Date
Sets the system date.
Format MM/DD/YYYY (month/day/year)
Total Memory
This field reports the memory size of the system. Memory size is fixed to 3017 MB.
N/A
Video Memory
Shows the video memory size. VGA Memory size=32 MB
N/A
Quick Boot
Allows startup to skip certain tests while booting, decreasing the time needed to boot the system.
Option: Enabled or Disabled
Network Boot
Enables, disables the system boot from LAN (remote server).
Option: Enabled or Disabled
F12 Boot Menu
Enables, disables Boot Menu during POST.
Option: Enabled or Enabled
D2D Recovery
Enables, disables D2D Recovery function. The function allows the user to create a hidden partition on hard disc drive to store operation system and restore the system to factory defaults.
Option: Enabled or Disabled
SATA Mode
Control the mode in which the SATA controller should operate.
Option: AHCI or IDE
