Chapter 5
Jumper and Connector Locations Top View
Item
Chapter 5
Description
Item
Description
JP1
Internal camera Connector
JBT1
Bluetooth Connector
JP2
TO PWR/B Connector
JMINI2
MINI Card (3G) Socket
JP3
TO USB/B Connector
SW2
Left Button
JP4
Internal DMIC Connector
SW3
Right Button
JP5
SIM Card Connector
SW4
Bluetooth Button
JP11
Internal TouchPad Connector
LED2
Battery LED
JP12
Internal Keyboard Connector
LED3
Media LED
JP20
Speaker Connector
LED4
Bluetooth LED
JLVDS1
LCD Connector
LED5
NUM LED
JREAD1
Card Reader Connector
LED6
CAP LED
135
