Removing the CRT Board 1. See “Removing the Upper Cover” on page 58. 2. Remove the single screw securing the CRT Board to the Lower Cover.
Step CRT Board
Size M2*5
Quantity
Screw Type
1
3. Lift the CRT Board left side first and turn it over to expose the CRT cable. IMPORTANT: Do not remove the board from the Lower Cover; the CRT cable is still attached.
