Hardware Specifications and Configurations Processor Item
Specification
CPU type
Intel Atom Z520(1.33GHz), Z530(1.6GHz) (Silverthorne)
CPU package
13 x 14mm, Micro-FCBGA
Core Logic
•
Mobile Intel® US15W Express Chipset
•
Intel Poulsbo AF82US15W (Controller Hub)
Chipset
•
Mobile Intel® US15W Express Chipset
Features
•
Hyper-Threading Technology
•
Intel® Virtualization Technology
•
Execute Disable Bit
Processor Specifications Item
CPU Speed
Z520
1.33 GHz
Z530
1.6 GHz
Bus Speed
Mfg Tech
1
533 MHz
1
533 MHz
Cores
Cache Size
Package
Core Voltage
45 nm
512 KB
MicroFCBGA
0.751.1V
45 nm
512 KB
MicroFCBGA8
0.751.1V
Acer P/N
CPU Fan True Value Table CPU Temperature of Diode
Fan Speed (RPM)
SPL Spec (dBA)
46
5000
26
52
5700
29
62
6400
31
72
7500
35
•
Throttling 50%: On=92C; Off=90C
•
OS shut down = 95C
•
H/W shut down = 100C
System Controller Hub Item Chipset
14
Specification Intel Poulsbo AF82US15W (Controller Hub)
Package
FCBGA 1249-pin
Features
•
400MHz and 533MHz FSB support
•
Maximum memory support: 2GB
•
Support for DDR2 at 667MHz and 533MHz
Chapter 1
