Bottom View
Item
158
Description
Item
Description
PJ1
Battery connector
CN16
RTC battery connector
PJ2
DC-in connector
CN17
Headphone connector
CN10
CRT board connector
CN18
Mini card for WLAN
CN11
USB connector
CN19
Mini card for 3G
CN12
SATA HDD connector
JSIM1
SIM card connector
CN13
DDR connector
U14
CPU Z520
CN14
USB connector
U15
Intel SCH
CN15
MIC connector
