Wheels and Tires
Wheel Specifications Size
Offset
20" - All Season - Front
Wheel Type
9.0J x 20
1.378" 35 mm
20" - All Season - Rear
9.5J x 20
1.575" 40 mm
20" - Summer - Front
9.0J x 20
1.378" 35 mm
20" - Summer - Rear
10.0J x 20
1.378" 35 mm
22" - Summer - Front
9.0J x 22
1.378" 35 mm
22" - Summer - Rear
10.0J x 22
1.378" 35 mm
Lug Nut Torque
129 lb. ft (175 Nm)
Lug Nut Socket Size
21 mm
Note: For instructions on how to jack/lift Model X, see Jacking and Lifting on page 172.
Tire Specifications Tire Type
Size
Load Index / Speed Rating
20" - Continental - Front
265/45R20
108 / V
20" - Continental - Rear
275/45R20
110 / V
20" - Michelin - Front
255/45R20
105 / Y
20" - Michelin - Rear
275/45R20
110 / Y
22" - Goodyear or Pirelli - Front
265/35R22
102 / W
22" - Goodyear or Pirelli - Rear
285/35R22
106 / W
Refer to the tire pressures printed on the Tire and Loading Information label. This label is located on the driver’s door pillar and is visible when the driver’s door is open (see Maintaining Tire Pressures on page 160). Winter tires can be purchased from a Tesla store.
