Vehicle Loading
Load Capacity Labeling It is important to understand how much weight your Model X can safely carry. This weight is called the vehicle capacity weight and includes the weight of all occupants, cargo and any additional equipment added to your Model X since it was manufactured. One or more labels attached to the center door pillar indicate how much weight Model X can safely carry. Labels are visible when the front door is open.
Note: Towing capability is available only if Model X is equipped with the Towing Package. Tire pressure information, along with other information related to towing, is located in the topic "Towing a Trailer" in the Driving section of the onscreen owners manual.
Tire and Loading Information Label The Tire and Loading Information label provides: • • • •
The maximum number of occupant seating positions. The maximum vehicle capacity weight. The size of the original tires. The cold inflation pressures for the original front and rear tires. These pressures are recommended to optimize ride and handling characteristics.
U.S. and Canada: 1. 2. 3.
Towing label (if equipped) Tire and Loading Information label Vehicle Certification label
Note: Towing capability is available only if Model X is equipped with the Towing Package. Warning: Overloading Model X has an adverse effect on braking and handling, which can compromise your safety or cause damage.
Mexico:
Caution: Never load more than 175 lbs (80 kg) on the rear load floor (above the lower trunk compartment) or more than 130 lbs (60 kg) in the lower trunk compartment. Doing so can cause damage. Caution: Never store large amounts of liquid in Model X. A significant spill can cause electrical components to malfunction.
Towing Label If equipped with the towing package, the Towing Label instructs you to refer to this owner's manual for tire pressures that should be used when towing a trailer. Do not use the tire pressures printed on the Tire and Loading Information Label. Specifications
Never change this label, even if you use different tires in the future. Note: If Model X is loaded to its full capacity, double check all tires to ensure they are inflated to their recommended pressure levels. Warning: Tire pressures printed on the Tire and Loading Information label DO NOT APPLY to towing. When towing, tire pressures must be increased. For information about the tire pressures required when towing, see Towing and Accessories on page 75. 175
