Fluid Reservoirs
Removing the Maintenance Panel
Checking Brake Fluid
To check fluid levels, remove the maintenance panel: 1. 2.
Warning: Contact Tesla immediately if you notice increased movement of the brake pedal or a significant loss of brake fluid. Driving under these conditions can result in extended stopping distances or complete brake failure.
Open the hood. Pull the maintenance panel upward to release the clips that hold it in place.
The Brake indicator on the instrument panel alerts you if the quantity of fluid in the brake reservoir drops below the recommended level. If it displays while driving, stop as soon as safety permits by gently applying the brakes. Do not continue driving. Contact Tesla immediately. Fluid Level Check Caution: The maintenance panel protects the front trunk from water. When reattaching, make sure it is fully seated.
Checking Battery Coolant If the quantity of fluid in the cooling system drops below the recommended level, the instrument panel displays a warning message. Stop driving Model X as soon as safety permits and contact Tesla. Fluid Level Check Tesla checks the Battery coolant level at the regularly scheduled maintenance intervals. DO NOT REMOVE THE FILLER CAP AND DO NOT ADD FLUID. Doing so can result in damage not covered by the warranty. Do Not Top Up Battery Coolant Warning: Battery coolant can be hazardous and can irritate eyes and skin. Under no circumstances should you remove the filler cap and/or add coolant. If the instrument panel warns you that the fluid level is low, contact Tesla immediately. To maximize the performance and life of the Battery, the cooling system uses a specific mixture of G-48 ethylene-glycol coolant (HOAT). Contact Tesla for more specific information about the coolant.
170
Tesla checks the brake fluid level at the regularly scheduled maintenance intervals. Topping Up the Brake Fluid Do not top up your brake fluid. Tesla service does this when you bring Model X in for regular servicing. The following instructions are provided for information purposes and future reference only: 1. 2. 3. 4.
Clean the filler cap before removing it to prevent dirt from entering the reservoir. Unscrew the cap and remove it. Top up the reservoir to the MAX mark using the appropriate brake fluid. Replace the filler cap, ensuring it is fully secured. Warning: Only use new fluid from a sealed air-tight container. Never use previously used fluid or fluid from a previously opened container—fluid absorbs moisture which decreases braking performance. Warning: Brake fluid is highly toxic. Keep containers sealed and out of the reach of children. In the event of accidental consumption, seek medical attention immediately. Caution: Brake fluid damages painted surfaces. Immediately soak up any spills with an absorbent cloth and wash the area with a mixture of car shampoo and water.
Model X Owner's Manual
