Climate Controls
Overview of Climate Controls The climate controls are always available at the bottom of the touchscreen. By default, climate control is set to Auto, which maintains optimum comfort in all but the most severe weather conditions. When you adjust the temperature, the system automatically adjusts the heating, air conditioning, air distribution, air circulation, and fan speed to maintain your selected temperature. To override these settings, touch Auto (see Customizing Climate Control on page 124). The fan, heating, and air conditioning systems are powered by the Battery. Therefore, prolonged use decreases driving range. Note: The following illustration is provided for demonstration purposes only. Depending on vehicle options, software version, market region, and settings, the information displayed may be slightly different.
1.
2.
3.
4.
5.
6.
The front seats are equipped with heating/cooling pads. When operating, the top indicator turns red when heating or the bottom indicator turns blue when cooling. Note: If Model X is equipped with the optional cold weather package, you can also control seat heaters in the rear seats, heated wipers, and heated steering wheel by touching Controls > Cold Weather (see Controls on page 116). Touch the up or down arrow to set the cabin temperature. To apply a temperature setting to both the driver and passenger side at the same time, touch SYNC TEMP on the temperature popup that appears when you touch an arrow. Touch the fan icon to customize and automate climate control settings for the front and rear cabin. (See Customizing Climate Control on page 124.) Note: Rear climate controls are available only if Model X is equipped with six or seven seating positions. The windshield defroster distributes air flow to the windshield. Touch once to turn on, touch a second time to operate the heating and fan at their maximum level, and touch a third time to turn off and restore the air distribution, heating, and fan to their previous settings. Turn climate control system on/off. Note: The label on this button says Keep Climate On if you have set the climate control system to maintain your temperature settings when parked (see Customizing Climate Control on page 124). The rear window defroster warms up the rear window for 15 minutes, then automatically shuts off. Exterior side mirrors are also heated. Warning: To avoid burns resulting from prolonged use, individuals who have peripheral neuropathy, or whose capacity to feel pain is limited because of diabetes, age, neurological injury, or some other condition, should exercise caution when using the climate control system and seat heaters.
Using the Touchscreen
123
