ENGINE TORQUE CHART Sr No
Assembly Stage
Part Number
Torque Values
67
Flywheel Assembly
BOLT HEX M12 X 1.5 X 40 X 10.9
006017528V1
Pre 40-45 Final For Mounitng Flywheel to Crank Shaft 90-95
68
BOLT BANJO M14X1.5X26
001232932R1
30-35
Fuel filter pipe outlet connection
69
Fuel Filter Assy FLANGED BOLT M10X25
000020313E05
30-35
For mounting fuel filter to bracket
70
BOLT HEX (M8x1.25x14)
000020308E05
24-30
For mounting Fuel filter bracket
BOLT_M8x1.25x20
000012190P04
24-30
For mounting Feed pump to front cover
BANJO BOLT TURBO INLET
0303EM0160N
10-14
For conecting hose to feed pump0303EM0160N Fuel filter pipe inlet connection
71 72
Feed pump Assy
Part Name
73
Tractor Level Assy
BOLT BANJO M14X1.5X26
001232932R1
30-35
74
Oil Filter Assy
OIL FILTER ASSLY - YUNXT
006025734Y91
12-16
Remarks
ENGINE SUB ASSEMBLIES
ENGINE ASSEMBLY
74
