BRAKE ASSEMBLY MOUNTING 1
2
Assemble the brake assembly(Rh) & (Lh ) on RH side and Lh side resp. with 6 no. of bolts on each side applying sealant 912. Apply Torque (41-55) NM on bolts with torque wrench to fix brake assembly on rear housing
⚠
Assemble the breathers on brakes in proper direction & Torque (20-30) Nm.
NOTE:- Ensure free rotation of ball bearings after assembly.
No Grease or oil trace should be present in DRY BRAKE assembly. Assembly should be free from dust and foreign particles. Make sure liners to be presoaked before assembly of OIB BRAKES. Remove all protective caps before installing.
DROPBOX ASSEMBLY & MOUNTING ON REAR HOUSING 1
3 Fitment of Coupling (1) with 2 ball (3) & 1 spring (4) in the output shaft (2)
2
Press Front bearing (A) in output shaft sub assembly. Insert this sub assy through Dropbox (D), o/p gear (C), & inner bearing(B)
4
TRANSMISSION MAIN LINE ASSEMBLY
Fitment of retainer (R) on dropbox with sealant 5060 and press output shaft oil seal (S) in retainer.
Fix dropbox cover plate on dropbox sub assembly using 4 no. of bolts applying torque of 20-27Nm on it.
60
