SPEED SHIFTER ASSEMBLY & MOUNTING 1
Assemble outer cam Link (C) and shaft speed shifting (S) locking it with roll pin (R) ⚠ NOTEEnsure free rotation of shaft
5
Insert Circlip internal (C) with straight circlip plier. Insert Conical spring (S). Insert the Circlip Internal (C) in dropbox
2
Take upper Gear shifter on lever and then assemble the ball pivot (B) on lever (L) and lock both with roll pin (R).
6
Cover dropbox upper open end & shifter lever with r u b b e r boot(R). Fix it with h o s e clip (h) on lever & on dropbox with hose clip (H).
3
Take speed shifter housing (H) and (S) in housing (Hpress oil seal (O) in it.Insert the shaft gate shifter with spacer stopper ).
7
4
Insert the spring bias (S) on shaft and Fit cam link inner (L) with roll pin (R)
8
Insert the gear shifter (G) followed by assembly (S) of speed shifter lever and ball pivot gear shifter in speed shifter housing
Insert the shifter mounting dowel (D) on housing. Mount shifter sub assy with 515 sealant & tight it with 4 bolts (B). torque (60-70Nm)
TRANSMISSION MAIN LINE ASSEMBLY
49
