SPEED BOTTOM SHAFT MOUNTING 1
Press Ball bearing on counter shaft (22) And mount 1st & 2nd circlip on shaft after bearing with 90 Deg. Bend Plier
2
6
Fit 1st driven gear with NRB with application of oil & place front spacer on counter shaft NOTE- Ensure
⚠
free rotation of NRB With gear(28)
7 Fitment of ball bearing 6304N on bottom shaft using pressing dolly
Insert Bottom shaft sub assy from RH side in speed Housing
3
8 Fitment of 3rd and 4th driven gear on bottom shaft
4 Fitment of 2nd driven gear on bottom shaft sub assy in speed housing
5 Fitment of spacer on driven shaft
NOTE :- Ensure free rotation of ball bearing after assembly Ensure oil application on NRB
⚠
Fitment of circlip using 90o Bend plier. Fit counter shaft retainer applying sealant 515 and tighten it with bolt & washer. Apply torque 20-27 Nm to the bolts with torque wrench
NOTE :- Assembly should be free from dust and foreign particles
⚠
TRANSMISSION MAIN LINE ASSEMBLY
