BEAM HOUSING ASSEMBLY 1
6 Take diff case (17) & insert bevel gear RH (B) & LH (A) with thrust washers (C).
2 Insert 2 bevel pinion (12) with Pinion Thrust Washers (13) in differential case
3
Insert bevel pinion shaft (16) through both pinion. Press roll pin (11) after aligning Diff Case and shaft holes by Dolly for roll pin pressing
4
Apply sealant 638 on ring gear and Insert ring gear (9)on Differential Case Mount the bolt (8) & apply torque 118-125 Nm
Apply 515 sealant on side housing & dock complete sub assembly to the beam housing (For LH & RH)
7
1.Mount Bolt & apply Torque. 2.Apply Torque 45-55 NM
8
5
Insert LH & RH connecting shaft in beam housing
1.Mount breather on beam Housing. 2.Apply Torque 95-110 NM. 3.Mount Drain plug in beam housing with Torque 50-55 NM. 4.Mount Drain plug of Swivel Housing LH & RH Apply Torque 50-55 NM.
4WD FRONT AXLE ASSEMBLY
39
