SPLINE SHAFT ASSEMBLY LAYOUT
PART NUMBER.
REF.
DESCRIPTION OF PART
QTY.
006513358Y1
1
NUT Lock M30X1.5
1
006513358Y1
2
SPACER Oil Seal Mounting
1
006506912B1
3
OIL SEAL Retainer Rear Axle
1
006507407D1
4
CIRCLIP INT - LUG 62
1
006514373Y1
5
SHIM 58X62X0.1
A/R
006514295Y1
6
SPACER 58X62X4.5
A/R
006514294Y1
6
SPACER 58X62X4.0
A/R
006513391Y1
7
SPACER End
1
006513342Y1
8
BEARING Taper Roller SKF
2
006514372Y1
9
SPACER 31.75X38X0.1
A/R
006514290Y1
10
SPACER 31.75X38X6.0
A/R
006514289Y1
10
SPACER 31.75X38X5.5
A/R
006513990Y1
10
SPACER Inside
1
006513389Y1
11
SPACER Outside
1
006514288Y1
12
SHIM 33X43X1.4
A/R
006514005Y1
12
SHIM 33X43X1.3
A/R
006514004Y1
12
SHIM 33X43X1.2
A/R
006514003Y1
12
SHIM 33X43X1.1
A/R
006513770Y1
12
SHIM For Backlash Spiral Pinion Shaft
A/R
006513942Y91
*
SET Of two
1
‡
13
SHAFT Spiral Pinion (13T)
1
‡
14
GEAR Ring (30T)
1
006507816D1
15
O RING 27X30X2
