SWIVEL HOUSING SUB ASSEMBLY SWIVEL HOUSING SUB ASSEMBLY CRITICAL SETTINGS On Swivel housing, measure the GAP from bearing resting face to Swivel housing flange using tool “AGFAYNMG 003” For ExampleMaster height = 35.00 mm Measured reading = - 0.208 mm GAP = 35.000 + 0.204 = 35.208 mm
SIDE HOUSING SUB ASSEMBLY LH & RH 1
2
Assemble the Bearing 28X58X16 (006515144Y1) with Bevel Gear Intermediate (006513290Y1) & Assemble it to Side Housing
4
Assemble bearing 35X80X21 (000016299P04) in Bevel Pinion intermediate (006513289Y1). Assemble it to Side Housing
5
A s s e m b l e the Circlip (006505629D1) to Side Housing Inner Groove
Fit the O-ring (006513337Y1) to Side Housing Outer Groove
CRITICAL SETTING
3 A s s e m b l e the Spacer (006513385Y1) to Side Housing
Measure float of Bevel pinion Intermediate (26) with dial gauge or feeler gauge. Float should be 0.20 mm (maximum). Adjust float with shim
