Removing the LCD Panel 1. See “Removing the Camera Board” on page 78. 2. Remove the two securing screws from the LCD Panel.
Step LCD Panel
Size M2*4
Quantity
Screw Type
2
3. Remove the LVDS cable from the cable channel in the bracket.
4. Lift the panel as shown to expose the LVDS and Microphone cables. IMPORTANT: Do not remove the panel at this stage to avoid damaging the cables.
Chapter 3
79
