Chapter 5
Jumper and Connector Locations Top View
Item
Chapter 5
Description
Item
Description
JP2
To PWR/B connector
SW2
Left button
JP12
Internal keyboard connector
SW3
Right button
JP20
Speaker connector
SW4
Bluetooth button
JP11
Internal track-pad connector
LED2
Battery LED
JLVDS1
LCD connector
LED3
Media LED
JBT1
Bluetooth connector
LED4
Bluetooth LED
PJP1
To Power core connector
LED5
NUM LED
PJP2
Battery connector
LED6
CAPS LED
143
