Replacing the Power Board 1. Insert the Power Board FFC under the mylar cover as shown.
2. Pull the FFC through the Upper Cover until none of the FFC is visible from the underside.
3. Place the Power Board in the Upper Cover and slide 4. Replace the single securing screw to secure the it to the left to engage the securing clips. board to the Upper Cover.
108
Chapter 3
