Replacing the Mainboard 1. Connect the USB Board cable to the Mainboard.
2. Replace the adhesive to secure the cable in place.
3. Turn the Mainboard over and insert it into the Lower 4. Replace the single screw securing the Mainboard to Cover left side first to ensure the I/O ports pass the Lower Cover. through the casing.
5. Connect the Speaker cable to the Mainboard.
102
6. Connect the AC Power cable to he Mainboard and press down as indicated to secure the cable in place.
Chapter 3
