Assembly instructions Loading data file in wrapper module Equipment required – Acquire a standard "null modem" cable (A) or special data transfer cable (B), ref 0835 192.0.
A
(Fig. 1)
B 1 Connecting null modem cable – Remove protective cover from electrical box. – Remove protective cover from electronic control box. A
– Connect "null modem" cable (A) to electronic control box connector. – Connect other end of cable to CDS 5000. (Fig. 2) 2 Connecting data transfer cable – Remove protective cover from electrical box. – Connect round plug (DIAG plug) of special data transfer cable (B) to connector in wrapper electrical box. B
– Connect other end of cable to CDS 5000. (Fig. 3)
3
86
ABA VB - Rollant 255 Uniwrap - 0299 435 2
