Assembly instructions Checking transport attachment Checking original setting – Pull cable (A1) while continuing to push bale twister towards attachment by hand, to engage catch (A2) of bale twister (1) in attachment lug (27). A1
12
• If catch (A2) engages, setting is correct. Check, however, that bale twister and housing of driving gears for wrapping arms do not collide. If everything is correct, bale twister is ready for use. If there is a collision, refer to paragraph "Additional adjustments to attachment (Bale twister with initial locking)", page 81. • If catch (A2) does not engage, it must be adjusted. Refer to paragraph "Additional adjustments to attachment (Bale twister with initial locking)", page 81.
A2
(Fig. 12, 14)
13 Additional adjustments to attachment (Bale twister with initial locking) Adjusting housing/bale twister clearance Housing/bale twister clearance is adjusted by attachment (28) and attachment lug (28A). – Adjust position of attachment (28) on housing of driving gears for wrapping arms:
29 28
1
– Slacken screws (29). – Move attachment (28) according to oblong holes. 14
– Tighten screws (29). Tightening torque: 48.5 Nm (Fig. 14)
0299 435 2 - ABA VB - Rollant 255 Uniwrap
81
