Assembly instructions Fitting safety fixings
28
– Carefully push bale twister by hand towards attachment (28) or (37) (according to number of kit for equipping wrapper), in order to align holes of levers (26) with those of hinge brackets: bale twister must not collide with housing of driving gears for wrapping arms. (Fig. 9-11) Danger! 9
Risk of fatal injury. If bale twister falls accidentally, it can cause serious injury.
☞ Make sure that emergency stop switch is in safety position before handling bale twister.
☞ Make sure that engine is switched off and that ignition key has been removed. – Secure left and right levers (26) with pins (36) and spring clips (27). 27 Danger! 36
Damage to bale twister
☞ Do not transport wrapping baler when bale twister is not set in safety position. 26
(Fig. 10, 11) 10
27 36
25 11
80
ABA VB - Rollant 255 Uniwrap - 0299 435 2
