Assembly instructions
22
26 27 2 27
5
Setting in transport mode – Switch on tractor engine. – Raise wrapping table • Set three-way valve to position II (refer to decal). • Turn emergency stop switch (A) to release wrapper from its safety position.
A
6
• Press "Raise/lower wrapping table" key (Y) in Uniwrap control box: that triggers "Raise/lower wrapping table" function. • Press key (W) to raise wrapping table completely (see Fig. 8). Danger!
Y
Risk of fatal injury. If bale twister falls accidentally, it can cause serious injury.
W
☞ Nobody must stand in the bale twister swivel area when it is triggered by control box. 7
78
ABA VB - Rollant 255 Uniwrap - 0299 435 2
