Assembly instructions Fitting "transport position" attachment (bale twister with initial locking) – Fit attachment (28) on housing (L) of driving gears for wrapping arms with screws M10 (29) and contact washers (30).
L
Caution! Do not tighten screws completely to allow for adjustment of transport position. 21 – Check assembly of attachment lug (28A): 28A
• If bale is ejected to the left, attachment lug (28A) must be fitted on the right, as in Fig. (22).
28
• If bale is ejected to the right, attachment lug (28A) must be fitted on the left.
29
– If attachment lug (28A) is not fitted on correct side, fit on other side and check visually. Final adjustment to attachment is described in paragraph "Additional adjustments to attachment (Bale twister with initial locking)", page 81. 22
0299 435 2 - ABA VB - Rollant 255 Uniwrap
(Fig. 21, 22)
75
