Assembly instructions Checking magnet position – Switch on tractor engine. – Raise wrapping table: • Set three-way valve to Position II (refer to decal). • Turn emergency stop switch (A) to release wrapper from its safety position. 6
K
19
• Press "Raise/lower wrapping table" key (Y) in Uniwrap control box: that triggers "Raise/lower wrapping table" function. • Press (M) key to raise wrapping table slightly. – Switch off tractor engine. – Remove ignition key. – Check magnet alignment (K) with magnetic sensor (P) attached to wrapping table.
P
– Check distance separating magnet (K) from electronic sensor (P):
K
• If adjustment is correct, the distance between magnet (K) and sensor (P) is between 6 and 8 mm. 20
• If necessary, adjust position of the magnetic sensor (P) to obtain the necessary distance. (Fig. 19, 20)
74
ABA VB - Rollant 255 Uniwrap - 0299 435 2
