Assembly instructions Modifying wrapping arms Drilling new holes for fixing protective covers – Drill 6 new holes (R), 10 mm in diameter, above existing holes.
R
X = 30 mm
X (Fig. 14) R R
X X 14 Fitting protective covers – Refit wrapper roller/chassis assembly (P) on wrapping arm, using new holes (R) and original screws.
N P
Tightening torque: 24.5 Nm – Refit support (O) with original screws. Tightening torque: 24.5 Nm – Refit protective plate (N) with original screws. Tightening torque: 24.5 Nm 15
(Fig. 15, 16)
L
O
16 – Refit connector (L). L
(Fig. 17)
17
0299 435 2 - ABA VB - Rollant 255 Uniwrap
61
