F-code
Section
PS
S2.0 2550 Transmission
Version no
002
C-code
T-code
HMX,RMX
3. Removal 1. Park the truck on a level surface and make sure load wheels are blocked to prevent accidental movement. 2. Disconnect and remove battery from unit to prevent accidental operation. 3. Open access door on front of truck and remove from truck by lifting off hinge pins. 4. Remove kick panel around transmission. 4. Remove control handle stem assembly (1) (See Ccode 4100 for more information). 5. Disconnect wire harness plug, located between housing (13) and control panel also disconnect brake harness at that point. 6. Remove brake switch mounting bracket (3) by removing two bolts (11). 7. Remove handle wiring harness from housing (13). 8. Disconnect power cables from drive motor. Label and remove from transmission case and housing. Cables may be left attached to control panel on truck. 9. Remove brake application spring connecting brake lever to brake linkage. Spring is located just above brake drum on end of drive motor. Disconnect brake linkage from lever. 10. Remove set screw (16) and pin (15) to release brake linkage in handle pivot casting. Brake linkage cannot be removed from the transmission assembly at this time. 11. Remove six bolts (4) that secure housing (13) to transmission. Lift housing from transmission. WARNING Transmission assembly is secured to truck frame with bolts that mount pivot handle. When released transmission can fall away frame truck causing injury.
© BT Products
Return
Service Manual
1997-07-15
95
