PS S0.2 0450 Drive Motor Mounting Points Version no
000
T-code
HMX,RMX
WARNING With all four cap screws (3) removed from drive motor, the drive motor will be loose and can fall injuring you or damaging other equipment. 6. Remove drive motor from transmission and place drive motor assembly on a bench to continue disassembly. 6. At drive end armature shaft remove locknut and pinion gear from drive motor. 7. At commutator end armature shaft remove locknut and brake drum from drive motor. Lifting one brake shoe at a time the brake assembly mounting bolts can be removed without disassembling brake assembly. 8. Thoroughly clean gasket eliminator from mating faces of drive motor and transmission housing.
2.2. Installation 1. Thoroughly clean all parts with safety solvent or other non-corrosive cleaning fluid. Air dry all parts. The transmission should be assembled in a dirt-free area. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 psi. and then only with effective chip-guarding and personal protective equipment. 2. Install brake assembly by lifting on brake shoe at a time and installing mounting bolts. (See Brake section for proper installation and adjustment of brakes). 3. Install brake drum on drive motor armature shaft over the key. © BT Products
