PS Lift Frame
S0.0
0300
Version no
T-code
000
HMX,RMX
1.2. Inspection NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. Thoroughly clean all parts and remove all nicks and burrs with emery cloth. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 psi, and then only with effective chip-guarding and personal protective equipment. 2. Inspect pull rods (20) for excessive wear or bending. No cracks are allowed in pull rods (20) and must be replaced as a pair. If heavy wear or bending is found replace both pull rods (20). 3. Inspect wheel forks (17) for excessive wear or cracks. If cracks are found replace both wheel forks (17). 4. Inspect all pins for nicks, scratches, or scoring. If heavy scoring is found, or scratches that can not be removed with emery cloth, replace pin. 5. All bushings are to be replaced with new.
66
