M2.0 Technical Service Data
Version no
000
T-code
HMX,RMX
Technical Service Data MODEL RMX
HMX
Shunt wound
Shunt wound
Power
1.8 hp.
1.8 hp.
Duty factor
60 min.
60 min.
Minimum brush length
0.62 in.
0.62 in.
Minimum commutator diameter
2.80 in.
2.80 in.
Minimum brush spring tension
40 oz.
40 oz.
12 Volt - 302112-000 24 Volt - 305880-000
305880-000
DRIVE MOTOR Type
Part no TRANSMISSION/GEAR Type
Vertical Motor spiral-bevel output
Gear ratio
22:1
14.8:1
Oil volume
About 1 Quart
About 1 Quart
SAE 80W90
SAE 80W90
ATF
ATF
Normal temperature < +5oF-15°C WHEELS Drive wheel
10.5 in. x 5 in. x 6.5 in. 10.5 in. x 5 in. x 6.5 in.
Drive wheel weight without load with battery
lb
lb
Drive wheel weight with rated load and battery
lb
lb
250 ft-lb
250 ft-lb
3¼ in. x 6 in.
3¼ in. x 6 in.
lb
lb
Torque axle nut Load wheel Load wheel weight with rated load, lb
