PS S7.0 Lift Cylinder
7310
Version no
T-code
000
RMX,HMX,CMX
5. Installation 1. In order to prevent air from filling the cylinder assembly it is recommended that the cylinder rod is fully retracted. 2. Install shims (25) and upper links (23,26) on cylinder assembly. 3. Slide lifting frame pivot pin (1) through lifting frame and upper links (23,26) and secure with a roll pin (30). 4. Install pivot pin (22) in carrier frame and upper links (23,26) and secure with cap screw (16). 5. Install one shoulder bolt (102) and one flat washer (101) though carrier frame and in cylinder rod. 6. Uncap and connect hydraulic hose to cylinder assembly and lift pump. 7. Install and connect battery to truck. Cylinder Assembly
8. Lift truck and remove all blocking. 9. Operate the truck’s hydraulic system and check operation of system as a whole looking for leaks and tight places on the lifting linkage.
101 102
WARNING DO NOT use your hands to check for hydraulic leakage. Use a piece of cardboard or paper to search for leaks. Escaping fluid under pressure can penetrate the skin causing serious injury. Relieve pressure before disconnecting hydraulic or other lines. Tighten all connections before applying pressure. Keep hands and body away from pinholes and nozzles which eject fluids under high pressure. 10. Close access door.
326
