F-code
Section
PS
S7.0
Version no
000
C-code
7310 Lift Cylinder
T-code
RMX,HMX,CMX
4. Assembly NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly.
Inlet Port
1. All parts should be cleaned and dried thoroughly. Metal parts should be lightly oiled prior to reassembly. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 psi. and then only with effective chip-guarding and personal protective equipment. 2. Install new rod seal (5) in cylinder body (2). Install new rod wiper (6) with lips facing inward to bottom of cylinder body (2).
1 2
3. Place new retainer ring (3) in groove of cylinder rod (4). 4. Oil outside of cylinder rod (4) and carefully insert in cylinder body (2).
3
4
5. Push cylinder rod (4) in cylinder body (2) until retainer ring (3) and cylinder rod (4) can be viewed through inlet port.
5
6. Using a screwdriver through cylinder body (2) inlet port, taking care not to harm port threads, slide retainer ring (3) in small groove. Rotate cylinder rod (4) and make sure retainer ring (3) is in the small groove all the way around cylinder rod (4). 7. Extend cylinder rod (4) to the fully out position to make sure retainer ring (3) is locked in place.
6
© BT Products
Return
Service Manual
1997-09-24
325
