PS S7.0 Lift Cylinder
7310
Version no
T-code
000
RMX,HMX,CMX
3. Inspection NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. Thoroughly clean all parts and remove all nicks and burrs with emery cloth. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 psi. and then only with effective chip-guarding and personal protective equipment.
1 2
2. Inspect cylinder body (2) for excessive wear or scoring. If heavy scoring is found replace entire cylinder assembly (1). 3. Inspect cylinder rod (4) for nicks, scratches, or scoring. If heavy scoring is found replace cylinder rod (4). 4. Inspect hydraulic hose and replace if worn.
3
4
5 6
324
