F-code
Section
PS M6.2 Lift Pump Assembly Version no
C-code
6140
T-code
001
4. Assembly NOTE! CLEANLINESS! Perform procedures in a clean environment. Make sure all parts are cleaned before disassembly and kept clean during assembly. 1. All parts should be cleaned and dried thoroughly. Metal parts should be lightly oiled prior to reassembly. WARNING Be extremely careful when working with solvent. Even a small explosion or fire could cause injury or death. WARNING Compressed air used for cleaning MUST be reduced to less than 30 psi. and then only with effective chip-guarding and personal protective equipment. 2. If pump motor was removed from endhead (10), install pump motor (7) by aligning scribe marks that were made earlier and secure with screws. 3. Connect power cables from pump motor to pump main solenoid (38) if this solenoid (38) was replaced. 4. Install coupler (8) on motor drive shaft. 5. Align splines on pump (24) shaft to splines on motor coupler (8). Gently push pump (24) shaft in coupler (8) and align pump (24) mounting holes in endhead (10). When pump (24) is flush with endhead (10), pump and motor are connected. 6. Install two cap screws (25) securing pump (24) to endhead (10) and tighten cap screws to 10-12 ft-lb. 7. Install strainer (21) on inlet tube (22) and thread on pump (24). 8. Oil O ring (11) lightly and install on endhead (10). 9. Start reservoir (18) over flange on endhead (10) up to O ring (11). Make sure it is aligned properly with holes as well as not cocked. 314
Return
Service Manual
1997-09-24
