PS S5.12 5460 24 Volt, 400 Amp Transistor Controller Version no
T-code
001
HMX
5.3. Technical Specification The technical specification for the BT-version of the Curtis 1244 transistor controller is according to the table below. PARAMETER
RANGE
STD SETTING
UNITS
DESCRIPTION
M1 Drive C/L
200 - 400
400
Amp
Main current limit
M1 Brake C/L *
100 - 400
200
Amps
Brake current limit
M1 Neut Brk % *
0 - 50
0
% of braking C/L
Neutral braking %
M1 Accel Rate *
0.1 - 5.0
0.5
Sec
Acceleration rate
M1 Max Speed *
0 - 44
40
% PWM duty cycle
Maximum speed
Seconds
Time to reach full drive output from zero output
M1 Brake Rate
268
Return
0.1 - 5.0
0.5
